Ozobot Classroom

Lesson Creator

  • Preparation
  • Direct Instruction
  • Student Practice
  • Supplements
  • Review

1. Tell Us About Your Lesson

All fields are required unless marked as optional

A. Lesson Overview


Students will

B. Lesson Details

Lesson Duration (minutes)The time (minutes) to complete the whole lesson.

Grade LevelsSelect all that apply


Subjects/TopicsChoose the most relevant subject(s). Select up to 3.


    Coding Styles


    Product Lessons


    Tested With

    2. Preparation

    This helps the teacher prepare for the lesson before the class session

    A. Student Materials

    B. Background Knowledge (Optional)

    C. Lesson Tips (Optional)

    Add tips for the educator that don't fit into Direct Instruction or Student Practice. You can always return to this page to add more.

    • The Basic Training lessons serve students and teachers as the introductory courses in computer science and robotics. While no computer science or robotics background is needed, be sure to set behavioral and material expectations with your students.
    • For some students with fine motor issues, Color Code Stickers may reduce frustrations. There are
    some included in the classroom kit and you can order more using the order form in your Classroom Kit Binder.
    • Additionally, we have found that correcting mistakes or adding Color Codes to an area of a line
    where no space was left, Avery™ Easy Peel White Inkjet Address Labels are extremely helpful.
    • Finally, graph paper may be helpful for students just starting out drawing Color Codes. The boxes
    are the perfect size for drawing Color Code boxes, and provide the ideal width of line for Ozobot to follow.
    • While Basic Training Lessons are broken up into four lessons, which can be taught individually, or all together. Each lesson will be no longer than 15-20 minutes, but if taught all at once, the time will be reduced since you will only need to distribute materials one time.
    • Before the lesson begins, ensure your students know how to calibrate the Ozobot. Follow our Calibration Tips: https://files.ozobot.com/stem-education/ozobot-calibration-tips.pdf
    • Introduce the following computer science vocabulary:
    Coding- forming a set of instructions to be executed by a computer, for younger learners, coding can be defined as telling a computer what to do. Robotics- the area of computer science that deals with robots Execute- to run the code you wrote Debugging- to fix any errors, or bugs, in code.

    Before launching your first lesson:

    1. From “Lessons for this Class,” select “View Materials” to see the lesson plan and materials needed.
    2. Print the Lesson Plan to have on-hand while the lesson is being run.

    To Launch a Lesson (for Color Code lessons):

    1. Plug your Classroom Communicator into your computer or USB power source
    2. Plug your Evos into their charger and plug the charger into the wall.
    3. Select “Launch Lesson” and follow instructions to connect your Classroom Communicator
    4. The student groups on your screen will each generate a color sequence to match it the front lights of their assigned Evo. Keep Evos in their charger until all of their front lights have changed color to match the assigned group
    5. Have students collect the Evo with lights matching the color sequence next to their group number (you may need to project your screen to your class so they can see their Evo’s color sequence)
    6. The lesson timer will begin when students remove their Evo from the charger.
    7. Follow the lesson plan according to the PDF instructions and see Live Lesson Insights from Ozobot Classroom as your students complete the activity.
    8. The lesson timer will stop when an activity is completed, or you can select “End Lesson”
    9. View the Post-Lesson Summary
    10. To turn Evos off after being connected, press and hold the power button for 10 seconds and return Evos to their chargers
    11. Disconnect your Classroom Communicator

    3. Direct Instruction (Teacher-Facing Instructions)

    These are the steps the educator will read. Include any front loading, modeling or explicit instruction before students work independently or in groups.

    Instruction

    Introduce the Ozobot. Tell students, “A robot is a machine that can be programmed to do certain tasks. They are used for many different things, including keeping humans safe from dangerous or boring jobs, getting into small places, doing jobs faster and better than humans can, and much more. From exploring space and the ocean to helping out with household chores, robots can be found all over. They come in all different shapes and sizes.”

    Instruction

    Show some videos of robots in action. Feel free to find your own videos/articles/ materials that are suitable for your individual classes’ interests! Amazon’s speedy shipping robots: goo.gl/daVH7m The Mars Curiosity Rover: goo.gl/1mjUrb A robot that goes to school in place of a student with a medical condition: goo.gl/EnVgKa This train doesn’t run on tracks; it has been programmed to follow lines: goog.gl/dKvajH

    Instruction

    Introduce the concept of coding. Coding and Computer Science is telling computers and robots what to do. Explain that the class will code the Ozobot, or tell it what to do, by drawing a path for it to follow with a black marker.

    Instruction

    Display the Ozobot. Turn Ozobot over (while it is powered on) and see what’s underneath. On the bottom, you can see eight lights shining out of them. An optical sensor lives in each of these openings. These sensors are Ozobot’s “eyes.” Each of the sensors sees how bright the paper underneath is. This way, Ozobot can differentiate the black and white parts of the paper to know where the line is! Explain that these are seven line following sensors. The sensor between the wheels is the color sensor, which will be utilized in latter Basic Training lessons.

    Instruction

    Tell students, “Ozobot is a robot you can program yourself! One way to program Ozobot is to use markers, paper, and Color Code to tell Ozobot where to go and what to do.”

    Instruction

    Model how to draw a line code, and how to execute the code by turning on the Ozobot and placing it on the line. Tell students to help Ozobot get from the start to finish by drawing lines that are “just right” for Ozobot to follow (¼ in (5mm)). Point out the chisel tip if using Ozobot markers. When you draw corners and curves, it is still necessary to make the line ¼ in (5mm) thick for Ozobot to follow it. Point out the power button and practice turning it on and off with your students.

    Instruction

    Display Lesson 1: Part 1 and Part 2 worksheets. Explain to students that their goal is to use the marker draw a line code to get their bot to get from start to finish.

    4. Student Practice (Student-Facing Instructions)

    These are step-by-step instructions delivered directly to the students as they work independently or in groups

    Student Instructions

    Instruction

    Look at Lesson 1: Part 1. Draw a line code to get your bot from start to finish. Execute the code. Did your bot make it? Check the box. If not, try again.

    Please upload any student resources, videos, etc. (Max. size: 512 MB videos, 10 MB all other files)

    Goal

    Instruction

    Look at Lesson 1: Part 2. Draw a line code to get your bot from start to finish. Execute the code. Did your bot make it? Check the box. If not, try again.

    Please upload any student resources, videos, etc. (Max. size: 512 MB videos, 10 MB all other files)

    Goal

    Lesson Extension (Optional)

    Add student instructions for a lesson extension.

    Instruction

    Draw your own line code! Practice more turns, curves and lines.

    Please upload any student resources, videos, etc. (Max. size: 512 MB videos, 10 MB all other files)

    Goal

    5. Supplements

    A. Lesson Closure (Optional)
    Give tips for how to wrap up the lesson and assess student learning. (Want to add an attachment? Use Part C, below.)

    Gather students for a discussion. Ask students: How did you code your Ozobot? How did the Ozobot read the code? How do you know if the Ozobot executed the code? Did your bot follow the entire path? Why/why not?

    B. Academic Standards (At least one standard required)
    Choose a category from the dropdown on the left. In the blank on the right, begin typing the number of the standard.

      C. Add Other Attachments (Optional)
      Please upload any student handouts, videos, sample solutions, etc. (Max. size: 1 GB videos, 10 MB all other files)
